| Pressure Range: | 20mm to 110mm (SDR 7.4) = 230 PSI at 20°C |
| 160mm to 315mm (SDR 11) = 150 PSI at 20°C | |
| Pipe Sizes: | 20mm – 315mm |
Description
AgruAir PE100 for Compressed AirAgruAir PE100 for Compressed air piping products are specifically designed for compressed air and have CRN certification. AgruAir PE100 is made of Solvay Eltex TUB 124 blue high density polyethylene (HDPE) resin and is extremely ductile, light weight, corrosion resistant and creates minimal system pressure drop. Installation is faster, more flexible and lower cost than metal systems. AgruAir PE100 is not affected by condensate and moist environments which cause most metal systems to scale, pit or corrode, which result in increased system pressure drop. It is chemically resistant to synthetic and mineral oils in compressed air. AgruAir PE100 also provides excellent chemical resistance to a multitude of acids, alkalies and hydrocarbons. Applications: Temperature Range: |
✓ Excellent Resistance to Compressor Oils and Humidity ✓ Excellent Stress Cracking Resistance ✓ High Impact Resistance ✓ High Abrasion Resistance |
Technical
AgruAir PE100 Piping Systems Brochure (PDF)
AgruAir PE100 Piping Systems Technical Information (PDF)
Installs
Welders
Butt Fusion Welders:
Miniplast – Sizes 20mm to 110 mm (1/2″ to 4″)
Maxiplast – Sizes 20mm to 160 mm (1/2″ to 6″)
W-Series – Sizes 50mm to 630 mm (1-1/2″ to 24″)
Non-Contact (IR) Fusion Welders:
IR Miniplast – Sizes 20mm to 110 mm (1/2″ to 4″)
SP-110S – Sizes 20mm to 110 mm (1/2″ to 4″)
Socket Fusion Welders:
HSOC – Sizes 20mm to 63 mm (1/2″ to 2″)
W-3511 – Sizes 20mm to 110 mm (1/2″ to 4″)
