Wafer Check Valves – WP Series

The Chemline WP Series Wafer Check Valve is a non-return valve ideal for limited space installations. These valves are economical and available for large pipe sizes, 2″ to 12″ and larger. They are available in two versions: with or without disc springs. The spring adds force for faster, more silent closing.

Polyvinyl Chloride
Pigmented Polypropylene
Polyvinylidene Fluoride
  • Size:
    2" to 12" (Valve sizes up to 24” and larger are available special order)
  • Body:
    PVC, PP, PVDF
  • Seats:
    PTFE
  • Seals:
    EPDM, FPM (Viton®), PTFE
  • Spring:
    316 Stainless Steel, Hastelloy

Features & Benefits

  • NSF 61 Approved Materials
    PVC/EPDM and PVDF/EPDM valves are made of NSF approved materials.
  • Compact
    Requires little space in piping systems.
  • Light Weight
    10″ PP valve weighs only 7 lbs.
  • Easy Installation
    Wafer body slips between standard flanges.
  • High Chemical Resistance
    A selection of materials of construction
    for every application.
  • Horizontal or Vertical Operation
  • Bubble Tight Shut-off
    Provided by replaceable o-ring seal.
  • Available With Disc Springs
    Faster disc closure reduces amount of back flow and consequent water hammer.
    Maximum closure is obtained with low pressure differential.
    Recommended for pulsating flows and horizontal piping.
  • Available Without Disc Spring
    For applications where no metals are desired.
    Lower cost.
