| Pressure Range: | 30 PSI at 95°C – 170 PSI at 10°C |
| Pipe Sizes: | 20mm – 110mm |
Description
High Purity Unpigmented PolypropyleneUPP pipe, fittings and valves are produced in a class 100 cleanroom, then the valves and fittings are hot DI rinsed and individually packaged. It is characterized by high operating temperature, high heat aging stability, good weldability, high chemical resistance, good elasticity and low frictional resistance Applications: USP purified water systems, Deionized water systems, RO water systems, Electronics industry chemical distribution systems, Photographic chemical processing, Food industry, Biotechnology process piping, Semiconductor manufacturing drain systems, Universities, Hospitals Temperature Range: 10°C to 95°C (50°F to 203°F) |
✓ High Creep Strength
✓ Low Specific Weight
✓ Usable on Food Applications
✓ High Abrasion Resistance
|
Technical
Unpigmented Polypropylene Piping Systems Brochure (PDF)
Piping Systems Technical Information (PDF)
Unpigmented Polypropylene Piping Systems Specification (PDF)
Welders
Butt Fusion Welders:
Miniplast – Sizes 20mm to 110 mm (1/2" to 4")
Maxiplast – Sizes 20mm to 160 mm (1/2" to 6")
W-Series – Sizes 50mm to 630 mm (1-1/2" to 24")
Non-Contact (IR) Fusion Welders:
IR Miniplast – Sizes 20mm to 110 mm (1/2" to 4")
SP-110S – Sizes 20mm to 110 mm (1/2" to 4")
Socket Fusion Welders:
HSOC – Sizes 20mm to 63 mm (1/2" to 2")
W-3511 – Sizes 20mm to 110 mm (1/2" to 4")
Pricing
| U-PP - Pipe, Valves and Supports | |
|---|---|
| SDR 11 Piping |  |
| Pipe Supports | |
| Diaphragm Valves | |
| T-Diaphragm Valves (zero dead leg) | |
| Butt Fusion Fittings | |
|---|---|
| 90 Degree Elbows | |
| 45 Degree Elbows | |
| Tees | |
| Concentric Reducers | |
| End Caps | |
| Female NPT Adaptors | |
| Male NPT Adaptors | |
| ANSI Stub Flanges | |
| ANSI Backing Rings | |
| Unions | |
| Sanitary Adaptors | |
| Socket Fusion Fittings | |
|---|---|
| Couplings | |
| 90 Degree Elbows | |
| 45 Degree Elbows | |
| Tees | |
| Reducing Tees | |
| Concentric Reducers | |
| End Caps | |
| ANSI Stub Flanges | |
| ANSI Backing Rings | |
